KM6801A-D Tuya Smart light and RF Remote Control Security Fog System

Key Selling Points:

• Smart Ecosystem Integration: Seamlessly connects to the Tuya Smart Life App, allowing for remote triggering, real-time status monitoring, and integration with other Tuya devices (e.g., smart lights, sensors) for automated scene-based activation.

• Industry-Leading Response Speed: Features patented 1-second cold-smoke trigger technology (no heat-up). It ejects dense, non-toxic fog for 15-20 seconds, creating a 30-45 minute visual barrier to secure areas up to 150m³.

• Multi-Mode Activation & Efficiency: Offers flexible triggering via the Tuya App, included RF remote control, or a wired panic button/switch. Features an automatic power-saving mode after activation and operates on very low power consumption (0-24W, DC12V/1A).

• Certified Safe & Reliable: Uses solid, dry, non-toxic fog formula that is safe for people and equipment. Backed by CE, ISO, RoHS certifications and non-toxic test reports. Robust design operates in a wide temperature/humidity range (-10°C to 50°C / 0%-80% RH).

• Professional & Easy Deployment: Simple wall or ceiling mounting for flexible installation in commercial spaces.

Target Use Case: Ideal for retail stores, small businesses, offices, and chain operations seeking to upgrade their security with a smart, connected solution. Perfect for integration into existing or new Tuya-based smart building systems to automate responses to break-ins (e.g., triggering fog, flashing lights, sounding alarms simultaneously).

Technical Parameter

Model Number	KM6801A-D
Fog System
Fog formula	Solid Dry Material, Non-toxic smoke
Fog performance	Cold smoke, 1 second triggered, protect critical area in 3 seconds, cover the protected area in 8 seconds.
Ejection time	15-20 seconds
Fog duration time	30-45 minutes
Heating time	NO need
Protect area	In closed or half closed Area (height2.5-3m), With filter is 100m³, Without filter is 150m³
Control
Trigger method	Remote control, panic button, On-off switch
Connection & active	Connect the IN+&IN-, press the remote control or panic button at least 2 seconds (suggest 5 seconds) to trigger fog. It switches to power saving mode after triggering.
Specification
Power	DC12V, 2A
Power consumption	0-24W
Working environment	-10℃~ 50℃/ humidity 0%-80%
Installation	Wall mount / ceiling mount
Certification	CE, NON-TOXIC test report
Patent	Design patent, utility model patent
Single package size	34X26X16 cm
Single gross weight	2.00 kg





In the box:

1.Security Fog Generator*1
2.Power Adapter*1
3.Bracket*1 and tool &screws*1set
4.Phoenix Plug*1
5.User Manual*1

6.Relay Module *1
